78 ProScreen
Design For Buckets Up To 82 inches
1 / 10
DESIGNED FOR MID SIZE EQUIPMENT
COMPACT WHEEL LOADER
MINI EXCAVATOR
YOU CAN SCREEN
FEATURES
FEED DEFLECTION SYSTEM + FLOW CONTROL WINGS
The FEED DEFLECTION SYSTEM combined with FLOW CONTROL wings is designed to ensure more uniform screening of materials in process. These systems enable material to enter the screener evenly, optimizing the efficiency of the operation. The FLOW CONTROL wings, unique and exclusive to the 78 ProScreen model, play a crucial role in controlling the flow of material, allowing larger particles like stones and other objects to pass through smoothly. These wings are adjustable, accommodating different material sizes, and then returning to their original position, ensuring consistent performance.
1 / 4
5 Year Structural Warranty
1 Year Electrical Warranty
MESH AVAILABLE
SQUARE
| Mesh Size | Pattern | Product Size |
|---|---|---|
| 5/32" x 5/32" | Square | 1/16" |
| 1/4" x 1/4" | Square | 1/8" |
| 3/8" x 3/8" | Square | 1/4" |
| 1/2" x 1/2" | Square | 3/8" |
| 1" x 1" | Square | 3/4" |
| 2" x 2" | Square | 1-1/2" |
| 3" x 3" | Square | 2" |
| 4" x 4" | Square | 3" |
ELONGATED
| Mesh Size | Pattern | Product Size |
|---|---|---|
| 3/8" x 4" | Elongated | 1/4" to 5/16" |
| 1/2" x 4" | Elongated | 3/8" to 7/16" |
| 3/4" x 4" | Elongated | 1/2" to 9/16" |
| 1" x 4" | Elongated | 3/4" to 7/8" |
