68 ProScreen
Design For Buckets Up To 66 inches
1 / 6
DESIGNED FOR COMPACT EQUIPMENT
MINI EXCAVATOR
MINI SKID STEER
YOU CAN SCREEN
FEATURES
CANTILEVERED SPRING SUSPENSION SYSTEM
Just like our other models, such as the 108 and 78, the 68 ProScreen is equipped with the Cantilevered Spring Suspension System. This advanced system allows the smaller screener to handle materials with moisture without any issues. The action and reaction of this system are essential for achieving the desired results in your screening process, ensuring smooth operation and consistent performance even with challenging materials.
1 / 3
MACHINE SPECIFICATIONS
MACHINE DIMENSIONS
Machine Width
89 inches
Machine Height
74 inches
Machine Depth
48 inches
SCREEN DECK
Screen Deck Width
68 inches
Screen Deck Length
52 inches
Screen Deck Surface area
27 sq/ft
Screen Deck Tilt Angle
45 to 30 Degrees
VIBRATORY SYSTEM
Vibratory Style System
Dual Eccentric Armature
Eccentric Rotation Speed
3600 rpm
Amperage Draw
10 each on start up with 5 Amps Amp draw per motor at 3600rpm
Eccentric Force rotation
760 lbs per/revolution
ELECTRICAL POWER SUPPLY
North America
110 Volt ( 60 Hertz )
WEIGHT
Total Weight
1500 lbs
5 Year Structural Warranty
1 Year Electrical Warranty
MESH AVAILABLE
SQUARE
| Mesh Size | Pattern | Product Size |
|---|---|---|
| 5/32" x 5/32" | Square | 1/16" |
| 1/4" x 1/4" | Square | 1/8" |
| 3/8" x 3/8" | Square | 1/4" |
| 1/2" x 1/2" | Square | 3/8" |
| 1" x 1" | Square | 3/4" |
| 2" x 2" | Square | 1-1/2" |
| 3" x 3" | Square | 2" |
| 4" x 4" | Square | 3" |
ELONGATED
| Mesh Size | Pattern | Product Size |
|---|---|---|
| 3/8" x 4" | Elongated | 1/4" to 5/16" |
| 1/2" x 4" | Elongated | 3/8" to 7/16" |
| 3/4" x 4" | Elongated | 1/2" to 9/16" |
| 1" x 4" | Elongated | 3/4" to 7/8" |
