108 ProScreen
Design For Buckets Up To 108 inches
1 / 10
DESIGNED FOR FULL SIZED EQUIPMENT
BACKHOE
WHEEL LOADER
YOU CAN SCREEN
FEATURES
FEED DEFLECTOR SYSTEM
Only DeSite recognized the need for a Feed Deflection System to optimize material flow. DeSite SLG screeners are uniquely equipped with a deflector that funnels material towards the top of the screen deck, initiating the screening process efficiently.
1 / 4
MACHINE SPECIFICATIONS
MACHINE DIMENSIONS
Machine Width
126 inches
Machine Height
122 inches
Machine Depth
72 inches
SCREEN DECK
Screen Deck Width
120 inches
Screen Deck Length
72 inches
Screen Deck Surface area
58 sq/ft
Screen Deck Tilt Angle
45 to 30 Degrees
VIBRATORY SYSTEM
Vibratory Style System
Dual Eccentric Armature
Eccentric Rotation Speed
3600 rpm
Amperage Draw
10 each on start up with 5 Amps Amp draw per motor at 3600rpm
Eccentric Force rotation
760 lbs per/revolution
ELECTRICAL POWER SUPPLY
North America
110 Volt ( 60 Hertz )
WEIGHT
Total Weight with riser box
5500 lbs
Total Weight without riser box
4300 lbs
5 Year Structural Warranty
1 Year Electrical Warranty
MESH AVAILABLE
SQUARE
| Mesh Size | Pattern | Product Size |
|---|---|---|
| 5/32" x 5/32" | Square | 1/16" |
| 1/4" x 1/4" | Square | 1/8" |
| 3/8" x 3/8" | Square | 1/4" |
| 1/2" x 1/2" | Square | 3/8" |
| 1" x 1" | Square | 3/4" |
| 2" x 2" | Square | 1-1/2" |
| 3" x 3" | Square | 2" |
| 4" x 4" | Square | 3" |
ELONGATED
| Mesh Size | Pattern | Product Size |
|---|---|---|
| 3/8" x 4" | Elongated | 1/4" to 5/16" |
| 1/2" x 4" | Elongated | 3/8" to 7/16" |
| 3/4" x 4" | Elongated | 1/2" to 9/16" |
| 1" x 4" | Elongated | 3/4" to 7/8" |
